Insulation Material: XLPE enhances thermal resistance, mechanical strength, and dielectric properties, allowing operation at temperatures up to 90°C (short-term tolerance up to 130°C).
Sheath Material: PVC provides robust protection against environmental factors (moisture, chemicals, abrasion) and ensures flame retardancy.
Voltage Range: Suitable for 0.6/1 kV to 26/35 kV systems, covering low-voltage to high-voltage applications.
FunctionalityHigh Current Capacity: XLPE insulation reduces energy loss and improves current-carrying efficiency compared to conventional PVC-insulated cables.
Flexibility: Suitable for complex routing in fixed installations such as ducts, trenches, or underground systems.
ApplicationsPower Distribution: Widely used in building electrical systems, substations, and industrial plants.
Infrastructure Projects: Ideal for urban grids, renewable energy systems (e.g., solar/wind farms), and transportation networks.
Advantages Over YJY CableCost-Effectiveness: YJV's PVC sheath is more economical than YJY's polyethylene sheath.
Environmental Resistance: YJY offers better resistance to water and corrosion due to its polyethylene sheath.
Longevity: XLPE insulation ensures a lifespan exceeding 30 years under normal conditions.
| Rated Voltage | 6/10kV, 6.35/11kV (12kV), 8.7/15kV, 12/20kV, 18/30kV, 19/33kV |
| Core Number | Single Core or Three Core (1C or 3C) |
| Available Dimensions | 25mm2 to 630mm2 |
| Conductor | Stranded round compacted copper or aluminum conductor (Cu / Al) |
| Insulation | XLPE (Cross-Linked Polyethylene) |
| Armouring | Single Core: Aluminium Wire Armoured (AWA); Multi-core: Steel Wire/Tape Armoured |
| Sheath | PVC, flame retardant PVC, PE, LSOH, HFFR |
| Temperature Rating | 0°C to 90°C |
